The realization of uniform surface accuracy by ideal nozzle arrangement and oscillation
The upper etching is an stand-alone pressure control, and furthermore, it is high-precision
Available for FPC transport
PCB etching (ferric chloride, cupric chloride, sulfuric acid/hydrogen peroxide, alkali etching)
Chemical milling (various metal etching, Fe, Al, Cu, Ti, etc.)
Equipment dimension (L×W×H) ： 8490 × 3400 × 1300 mm
Board size (effective width) ： 610mm
Process liquid ： ferric chloride etc.
Transportation rate ： 0.4～3.5m/min
Pass line ：
Operation system ：
*Equipment materials vary according to chemicals
*Please feel free to contact us for other special specifications
